How to start and drive a Borum line marking machine?
How does the combination machine (equipped with thermoplastic extruder and pressurized cold paint) work?
A combination machine can be used for applying both thermoplastic and cold paint markings in various widths.
Learn more here
What will happen to the oil temperature of the hydraulic tank if it exceeds more than 80 degrees centigrade?
If the oil gets too hot (more than 95 degrees centigrade) it will lose the ability to lubricate.
Learn more here
How to adjust the cable for Forward/reverse?
How to adjust the Toe-in (BM Master)
How to Adjust the Dual Torque Steering?
If the Adjustable pressure relief valve is turned clockwise, the pressure in the steering system will higher and the steering will be easier. If the Adjustable pressure relief valve is turned counterclockwise, the pressure in the steering will be lower and the steering will be harder.
Learn more here
How to change of Spline / Bearing for hydrostat
How to change the radiator for the engine on a BM 3000/5000
Drain diesel tanks. Remove the diesel tank (LEFT side). Loosen cover rear end. Drain radiator. Replace radiator
Learn more here
How to change the shaft/coupling BM 250-2 (Kubota Turbo)
How to update the handle for engine compartment BM 3000/5000
Make the holes for Bracket for the lock. Mount it. Mount the Bracket for door/engine room right/left With "Fork"
Learn more here
The machine does not move when set to forward or reverse position
This happens because of no grease. The grease nipple on the pulley should be greased at least once a month.
Learn more here
It is not possible to make lines/the lines are not regular
If the lines are not regular, it could be e.g. that the position of the sensor is not correct or that there is mechanical damage of the parts of the counting wheel.
Learn more here
The engine of the BM 3000/5000 (with relay control) shuts-down, why?
It could be e.g. missing oil pressure or water overheating (engine) or the compressor is overheating
Learn more here
What is the consumption per hour for BM T 250-2 / BM 2000 and preheaters 2 x ID-600 with PS-15 pump station? We need this for calculating the cost of application.
In this context, we estimate that the machine uses approximately 25kW when using the extruder (The engine output is 36 kW which is being exploited when applying spray plastic at 10 km/h).
Learn more here
The compressor is overheating. Why?
E.g. low oil level or low oil circulation inside the compressor.
Learn more here
How to adjust the standby pressure of the SCI8 compressor?
When the compressor is not making air the standby pressure (inside the compressor) must be about 3 bars. You must mount a gauge at one of the pressure ports and check that if the compressor is turning and the compressor is set to off (electric switch) then the pressure must be about 3 bars.
Learn more here
